| Quantity: | |
|---|---|
Model Number | Crimping lug |
Type | lug |
Name | bolted type lug |
what type of the connector: | shear bolt connector |
finished: | Acid Cleaning |
Material: | AL-99.6% |
Surface treament: | Tin-plated mini 15 microns |
Accordance: | IEC61238-1 |
Mechanical Shear Bolt Cable Connector are designed for use in low and medium voltage applications. Only three sizes cover conductor sizes from 25 mm2 to 400 mm².All products consist of a high strength and conductive body, at least two shear-head bolts. Optionally, inserts can be used for small conductor sizes.
Feature
- Suit to Conductor sizes 25-240mm2-good range taking ability
- Can be used with almost every type of conductor
- The forging process of aluminum alloy ensures high strength of the body
- Torque - controlled shear-head dolts guarantee a good electrical connection
- Easily installed with a normal socket wrench, no specialized equipment needed
- Fewer sizes cover a large range of cable sizes
- Can be used with both Copper and Aluminum Cables
- Connectors have central moisture barrier to allow connection between plastic and paper cables
- Connectors are High Tensile Ni/Sn-plated Aluminum
- Comply with IEC 61238-1 Class A
